Standard PLA
56MPa
Tensile Strength
2700MPa
Tensile Modulus
76.7MPa
Flexural Strength
2100MPa
Flexural Modulus
4-6%
Elongation at Break
38J/m
Izod Impact(Notched)
53℃
Heat Deflection Temperature
81.D
Hardness(Shore D)
standard
White
Grey
Black
Matte PLA
54.3MPa
Tensile Strength
2609.3MPa
Tensile Modulus
79.9MPa
Flexural Strength
2190.8MPa
Flexural Modulus
5-8%
Elongation at Break
35J/m
Izod Impact(Notched)
55℃
Heat Deflection Temperature
81.5
Hardness(Shore D)
Matte Finish
Black
White
Grey
PLA Pro
49.6MPa
Tensile Strength
2000MPa
Tensile Modulus
68.9MPa
Flexural Strength
2933.6MPa
Flexural Modulus
10-13%
Elongation at Break
45-48J/m
Izod Impact(Notched)
53℃
Heat Deflection Temperature
78.D
Hardness(Shore D)
High Speed
White
Grey
Black
-
TPU 95A
36MPa
Tensile Strength
11
Tensile Modulus
4.55MPa
Flexural Strength
/
Flexural Modulus
>370%
Elongation at Break
120KJ/m
Izod Impact(Notched)
110℃
Heat Deflection Temperature
95A
Hardness(Shore A)
standard
Clear
TPU 98A
36MPa
Tensile Strength
12
Tensile Modulus
4.55MPa
Flexural Strength
/
Flexural Modulus
>440%
Elongation at Break
125J/m
Izod Impact(Notched)
90℃
Heat Deflection Temperature
98A
Hardness(Shore D)
standard
Clear
-
PETG HF
50MPa
Tensile Strength
2412MPa
Tensile Modulus
75MPa
Flexural Strength
2205MPa
Flexural Modulus
8.2%
Elongation at Break
32J/m
Izod Impact(Notched)
75°C
Heat Deflection Temperature
78.5D
Hardness(Shore D)
standard
White
Grey
Black
Matte PETG
31MPa
Tensile Strength
1380MPa
Tensile Modulus
62MPa
Flexural Strength
2014MPa
Flexural Modulus
9.8%
Elongation at Break
60J/m (Notched)
Izod Impact(Notched)
67°C
Heat Deflection Temperature
73.5D
Hardness(Shore D)
standard
White
Grey
Black
-
COMING SOON……
